PicoStar

NanoStar

Q-switched Nd:YAG dual wavelength (1064/532nm)
Two wavelengths give physicians the flexibility to adapt treatments precisely to the patient’s needs and to a wide range of pigment colors (from darker colors to red). The ultra-short pulses of the Q-switched make it possible to burst the particles without any thermal side effects or scars. This increases patient comfort.

Reliable, fast and powerful
The Studio can be operated for a long duration, even in regions with higher temperatures and higher humidity, at a maximum speed of 10 Hz. This makes it one of the fastest and most reliable systems on the market. Its unmatched power output enhances your application spectrum, in addition to providing greater flexibility and efficiency.

Square-shaped spot with automatic spot size detection
The special shape of the spots is designed to guarantee the optimum coverage of the treatment area with greater efficiency. Unlike conventional circular spots, the square spot prevents “gaps” and overtreatment. Automatic spot detection allows different conditions on every part of the body to be treated in a fast, safe and efficient way.

Flat-Top OPTIBEAM® technology
An exclusive lens system creates a homogeneous spot (as opposed to a “hot spot”) by distributing the laser energy in a perfectly uniform way. This eliminates the need for overlap and prevents over-treatment. This results in less pain, lower bleeding levels and faster treatment.

TECHNICAL DATA
Laser: Nd:YAG, class 4
Wavelength: 532, 585, 650, 1064 nm
Energy: max. 800 mJ
Power: > 2.5 GW
Pulse duration: < 300 ps
Frequency: max. 10 Hz
Spot sizes: 2-5 mm (ST) | 5-10 mm (XL) | 2.5 x 2.5 mm (DYE)
Dimensions: 42 x 116 x 106 cm (W x D x H)
Weight: approx. 160 kg

​

Nd:YAG dual wavelength (1064/532nm)
Two wavelengths give physicians the flexibility to adapt treatments precisely to the patient’s needs and to a wide range of pigment colors (from darker colors to blue and red).

Highest energy and shortest pulses
The PicoStar uses the latest technology with the highest power to generate pulses below 300 ps for the most effective treatment of pigments and multicolored tattoos. The system can operate for a long duration with high speed and without the need of pre-pulses for the user. This makes it one of the fastest and most reliable PICO systems on the market. The ultra-short pulses allow bursting the pigment particles without any thermal side effects or scars. This increases patient comfort and providing greater flexibility and efficiency.

Zoom handpiece with different spot sizes
The PicoStar has an ergonomic, thin and light zoom handpiece. It is made of stainless steel for easy handling and cleaning. Thanks to a rotating ring on the handpiece, the spot size can be adjusted without changing the handpiece or tip. This offers you the flexibility to work on both larger and smaller areas with the maximum degree of precision.

Uniform beam profile and automatic spot detection
A special lens system creates a uniform spot without “hot spots” by distributing the laser energy in a perfectly way. This results in less pain and lower bleeding levels. The shape of the spot is designed to guarantee the optimum coverage of the treatment area with greater efficiency. The zoom handpiece with automatic spot detection allows flexible and easy adjustment for all applications and body regions. This ensures fast, safe and efficient treatment with a convincing result.

​DYE handpieces: maximum effectiveness even on lighter pigments
The green wavelength of the Nd:YAG laser (532 nm) can be transformed into yellow or red light. The special wavelength of 585 nm or 650 nm allow the treatment of the most difficult colors, such as green, blue, lilac and lighter colors.
